Cutter-mixer & emulsifier

KE-4V

Bowl capacity: 4.4 l. Adjustable speed with "brushless" technology.

Compact ULTRA line. Variable speed motor block + 4.4 l cutter bowl with lateral stirrers.
Ideal for emulsions and texturizations.
Brushless technology: maximum efficiency.

PlugUSA (NEMA 5-15P / 2P+G)
Bowl capacity4.65 qt
Max. product capacity5.5 lb
Maximum capacity (liquid)2.5 qt
Bowl dimensions: Ø7.6" x 6.34"
Total loading2 Hp (11 A)
Speed, min-max300 rpm - 3000 rpm
External dimensions (W x D x H)
Width9.9"
Depth12.2"
Height17.1"
Net weight26.2 lb
Crated dimensions
11.2 x 15.2 x 27.4 "
Volume Packed0.08 m³
Gross weight35.5 lbs.

Equipped with "brushless" technology: powerful and efficient motors.

  • Maximum efficiency: maintain the torque throughout the speed range.
  • Lightweight and compact design: they weigh less, they occupy less space.
  • Improved air/water-tightness since no ventilation is required.
  • They generate less noise: improved workplace environment.

Efficiency and performance.

  • Possibility of programming by time and pulse button.
  • 4.4 lt-bowl equipped with lateral stirrer and high shaft for larger production capacity.
  • Transparent lid equipped with hole to add ingredients in use.
  • Lid complete with gasket to avoid product overflowing.
  • Homogeneous and fine mixing result thanks to the lateral stirrers and inverted blade.
  • The lateral stirrers avoid product overheating.
  • Very uniform finish due to the movement generated the special position of the cutting edges.
  • Depending on usage, optional smooth or perforated blades available.
  • Built-in parametrisable programs to obtain the desired texture in seconds and in a standardized way: dense texture, fine texture, pulses (PrecisePulse function).
  • Option to customize programs for recipe standardization.
  • Optional vegetable slicer attachment available.

Built to last

  • Sturdy construction in food-grade best quality materials.

Maximum comfort for the user

  • Cutter bowl equipped with ergonomic handle.
  • Advanced control panel that is very intuitive to use and offers all the information at a glance.
  • Control panel equipped with timer to standardise processes.
  • Recessed cord relief allowing flush against wall operation

Maintenance, safety, hygiene

  • Safety microswitches in the position of the bowl and the lid.
  • Complete error warning system.
  • Appliance certified by NSF International (regulations on hygiene, cleaning and materials suitable for contact with foods).
  • 100% tested.

Equipment

Documents

Spec sheet

ps_en-US_33911_KE-4V.pdf

download

Instructions

Vegetable preparation machine - Cutter CK-24V / CA-2V / KE-4V (pdf)

download

Instructions

Vegetable preparation machine-cutter CK-35V/38V/45V/48V CA-3V/4V KE-5V/8V (pdf)

download

Declaration of conformity

Cutter-emulsifyers K-52/82/KE-5V/8V (pdf)

download

Declaration of conformity

Food-Processor K/KE (pdf)

download

Comparison

ACTIVEULTRA
K-41KE-4VKE-5VKE-8V
K-41KE-4VKE-5VKE-8V
Selection guide
Covers (from / to)10 - 5010 - 5020 - 7520 - 100
Max. product capacity5.5 lb5.5 lb7 lb8.75 lb
Features
Bowl capacity4.4 l4.4 l5.5 l8 l
Bowl dimensionsØ 7.6 x 6.34"Ø 7.6 x 6.34"Ø 9.4 x 5.9"Ø 9.4 x 7.8"
Total loading1.5 Hp2 Hp3 Hp3 Hp
Variable speed1800 rpm300 - 3000 rpm300 - 3000 rpm300 - 3000 rpm
External dimensions (W x D x H)
External dimensions (W x D x H)9.9 x 12.2 x 17.1"9.9 x 12.2 x 17.1"11.3 x 15.2 x 19.2"11.3 x 15.2 x 20.4"
Net weight31.3 lb26.2 lb39.7 lb41.7 lb

Video

Stirrers of the Sammic food processors

Compact line

KE Ultra: standardise your recipes with the cutter Ultra programs
