Cutter-mixer & emulsifier
KE-4V
Bowl capacity: 4.4 l. Adjustable speed with "brushless" technology.
Compact ULTRA line. Variable speed motor block + 4.4 l cutter bowl with lateral stirrers.
Ideal for emulsions and texturizations.
Brushless technology: maximum efficiency.
| Plug | USA (NEMA 5-15P / 2P+G) |
| Bowl capacity | 4.65 qt |
| Max. product capacity | 5.5 lb |
| Maximum capacity (liquid) | 2.5 qt |
| Bowl dimensions: Ø7.6" x 6.34" | |
| Total loading | 2 Hp (11 A) |
| Speed, min-max | 300 rpm - 3000 rpm |
| External dimensions (W x D x H) | |
| Width | 9.9" |
| Depth | 12.2" |
| Height | 17.1" |
| Net weight | 26.2 lb |
| Crated dimensions | |
| 11.2 x 15.2 x 27.4 " | |
| Volume Packed | 0.08 m³ |
| Gross weight | 35.5 lbs. |
Equipped with "brushless" technology: powerful and efficient motors.
- Maximum efficiency: maintain the torque throughout the speed range.
- Lightweight and compact design: they weigh less, they occupy less space.
- Improved air/water-tightness since no ventilation is required.
- They generate less noise: improved workplace environment.
Efficiency and performance.
- Possibility of programming by time and pulse button.
- 4.4 lt-bowl equipped with lateral stirrer and high shaft for larger production capacity.
- Transparent lid equipped with hole to add ingredients in use.
- Lid complete with gasket to avoid product overflowing.
- Homogeneous and fine mixing result thanks to the lateral stirrers and inverted blade.
- The lateral stirrers avoid product overheating.
- Very uniform finish due to the movement generated the special position of the cutting edges.
- Depending on usage, optional smooth or perforated blades available.
- Built-in parametrisable programs to obtain the desired texture in seconds and in a standardized way: dense texture, fine texture, pulses (PrecisePulse function).
- Option to customize programs for recipe standardization.
- Optional vegetable slicer attachment available.
Built to last
- Sturdy construction in food-grade best quality materials.
Maximum comfort for the user
- Cutter bowl equipped with ergonomic handle.
- Advanced control panel that is very intuitive to use and offers all the information at a glance.
- Control panel equipped with timer to standardise processes.
- Recessed cord relief allowing flush against wall operation
Maintenance, safety, hygiene
- Safety microswitches in the position of the bowl and the lid.
- Complete error warning system.
- Appliance certified by NSF International (regulations on hygiene, cleaning and materials suitable for contact with foods).
- 100% tested.
Equipment
Included with the machine
- Variable speed motor block.
- Cutter bowl with toothed blades.
Optional
- Hub with smooth blades.
- Hub with perforated blades.
- Vegetable slicer attachment.
Available accessories
Cutter bowl
Optional cutter bowl for Compact line vegetable preparation machines, cutters and combi machines.
Vegetable preparation attachment for K-41 / KE-4V
Allows to obtain a combi model out of a cutter-emulsifier.
Hubs with blades
Hubs with different blades for cutters / emulsifiers and combi models.
Documents
Comparison
| ACTIVE | ULTRA | |||
|---|---|---|---|---|
 |  |  |  | |
| K-41 | KE-4V | KE-5V | KE-8V | |
| Selection guide | ||||
| Covers (from / to) | 10 - 50 | 10 - 50 | 20 - 75 | 20 - 100 |
| Max. product capacity | 5.5 lb | 5.5 lb | 7 lb | 8.75 lb |
| Features | ||||
| Bowl capacity | 4.4 l | 4.4 l | 5.5 l | 8 l |
| Bowl dimensions | Ø 7.6 x 6.34" | Ø 7.6 x 6.34" | Ø 9.4 x 5.9" | Ø 9.4 x 7.8" |
| Total loading | 1.5 Hp | 2 Hp | 3 Hp | 3 Hp |
| Variable speed | 1800 rpm | 300 - 3000 rpm | 300 - 3000 rpm | 300 - 3000 rpm |
| External dimensions (W x D x H) | ||||
| External dimensions (W x D x H) | 9.9 x 12.2 x 17.1" | 9.9 x 12.2 x 17.1" | 11.3 x 15.2 x 19.2" | 11.3 x 15.2 x 20.4" |
| Net weight | 31.3 lb | 26.2 lb | 39.7 lb | 41.7 lb |
Video
Stirrers of the Sammic food processors
Compact line
KE Ultra: standardise your recipes with the cutter Ultra programs
