Commercial vegetable preparation machine
CA-3V
Commercial vegetable preparation. Production up to 1000 lb.
Variable speed motor block + universal head.
Equipped with "brushless" technology.
| Hourly production (pieces): 300 lb - 1000 lb | |
| Inlet opening | 21 in² |
| Disc diameter | 8" |
| Motor speed | 300 - 1000 rpm |
| Total loading | 3 Hp |
| Noise level (1m.) | <70 dB(A) |
| Background noise | 32 dB(A) |
| External dimensions (W x D x H) | |
| Width | 15.4" |
| Depth | 16.1" |
| Height | 21.7" |
| Crated dimensions | |
| 17.1 x 16.9 x 23.6 " | |
| Volume Packed | 0.11 m³ |
| Gross weight | 61.7 lbs. |
Ergonomic design
Perform the cutting operation in a single movement, achieving maximum production without fatigue for the user.
Lateral product ejection
It requires less space on the worktop and guides the product, avoiding splashes.
Variable speed
Adjust it to your needs at any moment.
Equipped with "brushless" technology: powerful and efficient motors.
- Maximum efficiency: maintain the torque throughout the speed range.
- Exclusive "force control system": guarantee of a uniform and high quality cut.
- Lightweight and compact design: they weigh less, they occupy less space.
- Improved air/water-tightness since no ventilation is required.
- They generate less noise: improved workplace environment.
A perfect cut
- High precision adjustments to obtain a uniform and excellent-quality cut.
- It can be fitted with a wide range of discs and grids of the highest cutting quality. Combining these accessories together to obtain more than 70 different types of cuts and grating grades.
- Exclusive "Force Control System" to optimise and standardise the cutting of each product: acoustic warning when the motor exceeds the pre-established force.
Built to last
- Made from stainless steel and food-grade materials of the highest quality: stainless steel motor block and food-grade aluminium head.
Maximum comfort for the user
- Ergonomic design: product sliced in one single movement.
- Lateral product output: requires less space on the worktop and guides the product, avoiding splashes.
- Advanced control panel that is very intuitive to use and offers all the information at a glance.
Maintenance, safety, hygiene
- Lever and lid easily removable for cleaning purposes.
- Combination of safety systems: head, cover, power switch.
- Appliance certified by NSF International (regulations on hygiene, cleaning and materials suitable for contact with foods).
- 100% tested.
Equipment
Included with the machine
- Variable speed motor block.
- Universal head.
- Universal grid cleaner QC-U.
Optional
- Tube head for long products.
- Support-trolley.
- Discs and grids.
- Grid cleaning kit.
Available accessories
FCC curved slicing discs
For slicing of soft products (CA / CK).
FCO rippled slicing discs
Designed to obtain rippled slices (CA / CK).
FFC chipping grids
Grid for fries for CA / CK.
FMC dicing grids
Dicing grids for CA / CK.
FCE julienne discs
For french fries, strips or batons.
Long vegetable attachment
For Sammic vegetable preparation machines and combi models.
Disc and grid packs - Heavy Duty
Set of discs and grids for a vegetable preparation machine.
Disc and grid holder
Ideal to store discs and grids when not in use.
Stand-trolley
Optional accessory for all Sammic vegetable preparation machines and combi models.
Quick Cleaner: grid cleaners
For an efficient, quick and safe grid cleaning operation.
FC-D slicing discs
Regular slicing discs for CA-31 / 41 / 3V / 4V and CK-35V / 38V / 45V / 48V.
SH shredding & grating discs
Shredding discs for Sammic vegetable slicers and combi vegetable slicer & cutters.
Déli-cut cutting kit - Heavy Duty
Kit for the exclusive Déli-cut cut of 4 x 4 x 8 mm.
Universal grid cleaner QC-U
To clean all grids of all veg prep machines.
Documents
Comparison
| ACTIVE | ULTRA | ||||||
|---|---|---|---|---|---|---|---|
 |  |  |  |  |  |  | |
| CA-21 | CA-31 | CA-41 | CA-61 | CA-2V | CA-3V | CA-4V | |
| Selection guide | |||||||
| Covers (from / to) | 10 - 50 | 100 - 450 | 100 - 600 | 200 - 1000 | 10 - 50 | 100 - 450 | 100 - 600 |
| Hourly production | 110 - 770 lb | 300 - 1000 lb | 400 - 1300 lb | 1000 - 2200 lb | 110 - 770 lb | 300 - 1000 lb | 400 - 1300 lb |
| Features | |||||||
| Inlet opening | 13.8 in² | 21 in² | 44.4 in² | 42.4 in² | 13.8 in² | 21 in² | 44 in² |
| Inlet shape | |||||||
| Motor speed | 1800 rpm | 365 rpm | 365 rpm | 365 rpm | 300 - 1000 rpm | 300 - 1000 rpm | 300 - 1000 rpm |
| Total loading | 1.5 Hp | 1.5 Hp | 1.5 Hp | 1.5 Hp | 2.0 Hp | 3 Hp | 3 Hp |
| External dimensions (W x D x H) | |||||||
| External dimensions (W x D x H) | 14.9 x 12.2 x 21" | 15.4 x 16 x 21.4" | 15.4 x 15.6 x 25.7" | 16.9 x 16.5 x 31.9" | 14.9 x 12.2 x 21" | 15.4 x 16.1 x 21.7" | 15.4 x 15.7 x 25.7" |
| Net weight | 33.5 lb | 46 lb | 52.9 lb | 62.8 lb | 28.4 lb | 53 lb | 59.5 lb |
Video
Force control system
CA: easy detaching for cleaning
CA Vegetable slicers - Heavy Duty
