Food processor / Veg prep combi machine
CK-48V
2 in 1: high capacity vegetable cutter (1300 lb) + cutter with 8 liter bowl.
It has a variable speed motor block, large-capacity head and 8 l cutter bowl equipped with a rotor with micro-serrated blades.
"Brushless" technology.
| Total loading | 3 Hp |
| As vegetable preparation machine | |
| Hourly production | 400 lb - 1300 lb |
| Inlet opening | 44.4 in² |
| Disc diameter | 8" |
| Speed as veg. slicer | 300 rpm - 1000 rpm |
| External dimensions (W x D x H) | 15.4" x 15.7" x 25.7" |
| Net weight | 67.9 lb |
| As cutter | |
| Bowl capacity | 8.5 qt |
| Speeds as cutter (positions) | 300 rpm - 3000 rpm |
| External dimensions (W x D x H):11.3" x 15.2" x 20.4" | |
| Net weight (Cutter) | 41.9 lb |
| Noise level (1m.) | <70 dB(A) |
| Background noise | 32 dB(A) |
| Crated dimensions | |
| 27.8 x 16.3 x 20.3 " | |
| Volume Packed | 0.15 m³ |
| Gross weight | 79.6 lbs. |
Equipped with "brushless" technology: powerful and efficient motors
- Maximum efficiency: maintain the torque throughout the speed range.
- Exclusive "Force control system": guarantee of a uniform and high quality result.
- Lightweight and compact design: they weigh less, they occupy less space.
- Improved air/water-tightness since no ventilation is required.
- They generate less noise: improved workplace environment.
Cutting function: a perfect cut
- High precision settings and comprehensive cutter and disc design aimed at obtaining a perfect cut.
- It can be fitted with a wide range of discs and grids of the highest cutting quality. By combining these accessories, you can achieve more than 70 different types of cuts and grating grades.
- Exclusive "Force Control System" to optimise and standardise the cutting of each product: acoustic warning when the motor exceeds the pre-established force.
Cutter function: efficiency and performance
- Possibility of programming by time and pulse button.
- Reverse function, ideal for mixing products instead of cutting.
- 8 litre stainless steel bowl.
- Transparent lid with built-in "cut&mix" mixer.
- Depending on the purpose, the possibility of using optional smooth or perforated blades.
- Built-in parametrisable programs to obtain the desired texture in seconds and in a standardized way: dense texture, fine texture, pulses (PrecisePulse function).
- Option to customize programs for recipe standardization.
Built to last
- Made from stainless steel and food-grade materials of the highest quality: stainless steel motor block and food-grade aluminium head. Stainless steel bowl with highly-resistant lid.
Maximum comfort for the user
- Ergonomic design. Maximum comfort for the user.
- Lateral product output: it requires less room on the work surface and directs the product avoiding splashing.
- Advanced control panel that is very intuitive to use and offers all the information at a glance.
Maintenance, safety, hygiene
- Plunger, lid and hopper easy to remove for changing or cleaning.
- Combination of security systems: head, covers, bowl, power switch.
- Appliance certified by NSF International (regulations on hygiene, cleaning and materials suitable for contact with foods).
- 100% tested.
Equipment
Included with the machine
- Variable speed motor block.
- Large capacity head.
- Cutter bowl, with micro-serrated blade rotor.
- Universal grid cleaner QC-U.
Optional
- Tube head.
- High production semi-automatic bowl.
- Discs, grids and disc support.
- Rotor with smooth cutting blades.
- Rotor with perforated cutting blades.
- Support-trolley.
- Grid cleaning kit.
Available accessories
FCC curved slicing discs
For slicing of soft products (CA / CK).
FCO rippled slicing discs
Designed to obtain rippled slices (CA / CK).
FFC chipping grids
Grid for fries for CA / CK.
FMC dicing grids
Dicing grids for CA / CK.
FCE julienne discs
For french fries, strips or batons.
FR shredding & grating discs
Shredding / grating discs (CA / CK).
Disc and grid packs
Set of discs and grids for a vegetable preparation machine.
Disc and grid holder
Ideal to store discs and grids when not in use.
Blades for CK / K / KE
Optional blades for sammic cutters and emulsifiers.
Quick Cleaner: grid cleaners
For an efficient, quick and safe grid cleaning operation.
FC-D slicing discs
Regular slicing discs for CA-31 / 41 / 3V / 4V and CK-35V / 38V / 45V / 48V.
SH shredding & grating discs
Shredding discs for Sammic vegetable slicers and combi vegetable slicer & cutters.
Documents
Comparison
| ACTIVE | ULTRA | |||||
|---|---|---|---|---|---|---|
 |  |  |  |  |  | |
| CK-241 | CK-24V | CK-35V | CK-38V | CK-45V | CK-48V | |
| Selection guide | ||||||
| Covers (from / to) | 10 - 50 | 10 - 50 | 100 - 450 | 100 - 450 | 100 - 600 | 100 - 600 |
| Hourly production | 110 - 770 lb | 110 - 770 lb | 200 - 1000 lb | 200 - 1000 lb | 400 - 1300 lb | 400 - 1300 lb |
| Features | ||||||
| Inlet opening | 13.8 in² | 13.8 in² | 21 in² | 21 in² | 44.4 in² | 44.4 in² |
| Inlet shape | Kidney | Kidney | Circle | Circle | ||
| Bowl capacity | 4.4 l | 4.4 l | 5.5 l | 8 l | 5.5 l | 8 l |
| Motor RPM (Cutter) | 1800 rpm | 300 - 3000 rpm | 300 - 3000 rpm | 300 - 3000 rpm | 300 - 3000 rpm | 300 - 3000 rpm |
| Speed as veg. slicer | 1 | 5 | 5 | 5 | 5 | 5 |
| Motor RPM (Veg.Prep.) | 1800 rpm | 300 - 1000 rpm | 300 - 1000 rpm | 300 - 1000 rpm | 300 - 1000 rpm | 300 - 1000 rpm |
| Loading | ||||||
| Single Phase | 1.5 Hp | 2 Hp | 3 Hp | 3 Hp | 3 Hp | 3 Hp |
| External dimensions (W x D x H) | ||||||
| Dimensions (Veg.Prep.) | 14.9 x 12.2 x 21" | 14.9 x 12.2 x 21" | 15.4 x 16.1 x 21.7" | 15.4 x 16.1 x 21.7" | 15.4 x 15.7 x 25.7" | 15.4 x 15.7 x 25.7" |
| Dimensions (Cutter) | 9.9 x 12.2 x 17.1" | 9.9 x 12.2 x 17.1" | 11.3 x 15.2 x 19.2" | 11.3 x 15.2 x 20.4" | 11.3 x 15.2 x 19.2" | 11.3 x 15.2 x 20.4" |
| Net weight (Veg.Prep.) | 33.5 lb | 28.4 lb | 53 lb | 53 lb | 59 lb | 59 lb |
| Net weight (Cutter) | 31.3 lb | 26.2 lb | 39.7 lb | 41.9 lb | 39.7 lb | 41.9 lb |
